Crown Steam, GLT-40F, Gas Steam Kettle, 120V, Tilting, Liquid Propane

SKU #: GLT-40F
Description
The Crown GLT-40F is a gas-fired, self-contained steam kettle featuring a double-wall interior that forms a steam jacket around the entire kettle. The jacket is sealed with factory-distilled water for optimal steam efficiency. The interior is made from type 316 stainless steel, specifically designed for high-acid content cooking, while the fully insulated exterior ensures excellent heat retention. The hemispherical kettle bottom ensures superior heat circulation, providing even cooking results. The recessed control panel is conveniently located on the front-right side of the unit, offering full visibility and ease of use. Standard controls include a direct immersion thermostat for operation within a temperature range of 165°F to 275°F (74°C to 135°C) at 50 psi, along with a water sight glass, cooking light, pressure gauge, and electronic ignition with an ignition indicator light. For safety, the GLT-40F is equipped with a low water shut-off with an indicator light, a pressure switch, pressure relief valve, and a 100% safety gas shut-off valve, ensuring reliable operation. The kettle pivots on trunnions connected to the tilt mechanism and control consoles, allowing the kettle to tilt past 90° for complete emptying. The drip-proof stainless steel-clad consoles are supported by all-welded, 1-5/8” (41 mm) diameter stainless steel legs with flanged feet, securely mounting the unit to the floor.
?
Specifications
Gas Inlet Size
0.75 Inch
Number of Steam Kettles
1
BTU
120000 BTU
Voltage
120V
Phase
1PH
Capacity
40 gallon
Kettle Capacity
40 Gallon
Height
41.25"
Depth
45.75"
Area (in)
59 in X 45.75 in X 41.25 in
Width
59"
Tilt Mechanism
Crank
Safety and Compliance
CSA Flame, CSA Star, NSF
Design
Freestanding, Indoor Only
Steam Type
generator
Product Type
kettle
Base Configuration
Legs
Power Type
Liquid Propane
Control Type
Manual
Plug Type
NEMA 5-15
Gas Type
Propane
Material
stainless steel
Steam Kettle Type
Standard
Style
tilting
Features
with full jacketed option
